OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 836 H.323 GK OPTION
DESCRIPTION:
Provides a means to set the MGI parameters for an optional external industry-
standard H.323 network gatekeeper, using Registration, Admissions, and Status
signaling (RAS). The settings are system wide.
¾ NOTE: When changing any IP address/value, listed below, three digits must
be input for each (octet) field. Example 192.168.1.10 input must be: 192 168
001 010
• GK CONNECTION: This determines if the MGI is to connect to a gatekeeper.
The options are: ENABLE or DISABLE.
• GK ROUTING: This enables or disables routing of calls through a gatekeeper.
The options are: ENABLE or DISABLE.
• GK IP ADDRESS: This is gatekeeper’s IP address.
• GK NAME: This is alphanumeric name identifier of the gatekeeper. An entry of 9
characters with a space followed by an additional 6 alpha-numeric characters.
• ALTER GK IP ADDR: This provide for an alternate gatekeeper address.
• H.323 GATEWAY ID: This is the H.323 identifier used by the MGI when
registering with the gatekeeper. This can be up to 16 characters in length.
• E.164 GATEWAY NO: This is the E.164 identifier used by the MGI when
registering with the gatekeeper. This can be up to 16 digits
in length.
• GK KEEP ALIVE: This is the timer that the MGI uses to acknowledge the
presence of the gatekeeper. The range is 000~999 seconds.
• GK DOWN ROUTE: This provides an alternate route in case the primary
gatekeeper is down. Selections are PSTN or ALTER GK.
• GK RAS TYPE: Select if AUTO or MANUAL, depending on your gatekeeper’s
capabilities.
• URQ REASON MODE: Select ON or OFF for usage of Unregister Request RAS
(URQ) messages.
