OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 JANUARY 2009
MMC: 806 CARD PRE-INSTALL
DESCRIPTION:
Allows the preprogramming of a card slot for a specific board type. A board inserted
into a OfficeServ 7100 system will not be recognized by the system until it is
ENABLED using this MMC. Cards installed using MMC 806 will NOT be assigned in
the system numbering plan. You must then use MMC 724 to assign the desired
directory numbers to extensions or trunks ports.
NOTE: If a card is removed and a different type card is inserted and this MMC is
performed, the memory associated with that card (i.e. key programming, etc.) will
be erased.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 806.
Display shows.
C:1 – S:1
UNI-DDN->UNI-DST
2. Press the right soft key to move cursor to the
“S” or slot position. Press the UP or
C:1 – S:1
UNI-DDN->UNI-DST
DOWN key to advance the slot position, or
use dial pad to make selection (eg. Change
from DDN to DST) N=none, D=DLM,
S=SLM, T=TRM)
3. Use the RIGHT softkey to make selection.
4. Use the dial pad (1=YES, 0=NO) to make
selection.
C:1 – S:1
ARE YOU SURE?
5. Press the UP or DOWN key to advance the
SLOT position. Now the display will show
C:1 – S:MP
MP10A-N->MP10A-N
the daughter slot of the MP10a card.
D=DLM, W=SWM, N=NONE
