OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 JANUARY 2009
MMC: 863 ACCESS NUMBER
DESCRIPTION:
This MMC is the program that specifies the system information of SPNet (Samsung
Proprietary Networking). It is useful when many systems are connected through
SPNet and interlocked with LCR. There are a maximum of 2000 entries.
Option Description
0 ACCESS NUM Other system’s ID
1 IP ADDR Other system’s ID address
2 TEL NUMBER Rerouting Trunk Number (excluding VoIP Trunk
Number). If SPNet function is not working, call is
rerouted through this trunk.
3 MAX COUNT If you dial a valid digit string until Max Count number,
the system set up call.
Note: SPNet is VoIP network function developed by Samsung and it is not standard
function.
Conditions:
LINK ID should not be inputed in MMC 820 SYSTEM LINK ID and ACCESS
NUMBER & TELEPHONE NUMBER should be input in the LCR table.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 863.
Display shows.
[0001] ACCESS NUM
2. Enter the node entry number
OR
[0001] ACCESS NUM
Press VOLUME button to select and press
Right soft button to move cursor.
3. Enter the option number
OR
[0001] ACCESS NUM
