OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 108 STATION STATUS
DESCRIPTION:
Displays the following attributes of a station port. This is a READ-ONLY MMC:
0 PORT # Cabinet (1~5)/Slot (1~3)/Port (1~12)
1 TYPE Device Type
2 PICKUP GROUP None, 01~20
3 SGR Station Group Number
4 BOSS-SECR None, 1–4
5 PAGE None, Page Zone (0 ~9, 4)
6 COS NO COS (1–30) per Ring Plan (01–06)
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 108
Display shows first station
[201] STN STATUS
PORT# : C1-MP-V01
2. Dial station number (e.g., 205)
OR
[205] STN STATUS
PORT# : C1-S1-P09
Press UP or DOWN to select station and
press RIGHT soft key to move cursor.
3. Dial 0~6 to select station status type
OR
[205] STN STATUS
TYPE: 28B SET
Press UP or DOWN to select status and press
RIGHT soft key to return to step 2.
4. Press TRANSFER to exit
OR
Press SPEAKER to advance to next MMC.
