OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 824 NETWORK DIAL PLAN
DESCRIPTION:
This MMC is the translation table that defines the extension dialing plan for the
networked systems.
PROGRAMMED FIELD DESCRIPTIONS: PP:NONE ¬ DDDD
SZ:X MAX:XX MB:XX
PP Dial Plan Number (01-99).
DDDD Link ID and leading digits for the extension numbers in that switch (8
characters maximum).
SZ Number of digts in extension number (0-9).
MAX Number of digits total (1-20) for ID number and extension number.
MB Create mailbox for this extension range in this switch (Y/N).
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
ACTION DISPLAY
1. Press TRANSFER 824.
Display shows.
01: NONE¬
SZ:0 MAX:00 MB:N
2. Press UP or DOWN key to select
plan number and press RIGHT
10: NONE¬___
SZ:0 MAX:00 MB:N
soft key to move cursor.
3. Enter LINK ID and FIRST DIGIT of
extension number using the keypad
10: NONE¬ 0033
SZ:0 MAX:04 MB:N
and press RIGHT soft key to move cursor.
4. Enter number of digits in the extension
number. Cursor advances to next field.
10: NONE¬ 0033
SZ:3 MAX:04 MB:N
5. Dial maximum number of digits. Cursor
advances to next field.
10: NONE¬ 0033
SZ:3 MAX:06 MB:N
