OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 829 LAN PRINTER PARAMETER
DESCRIPTION:
This program sets the various parameters required for printing to a LAN connected
device (PC or printer).
The eight types of data listed below can be displayed using the LAN printer or PC.
LAN TCP PORT
REPORT (TCP port of MCP providing the service)
[01] SMDR 5100
[02] UCD REPORT 5101
[03] TRAFFIC REPORT 5102
[04] ALARM REPORT 5103
[06] PERIODIC UCD 5105
Ports 5100 ~ 5106 are fixed and are displayed in the “LAN TCP” field below.
The items that are set in this program are listed below.
00 DATA TYPE Type of data to be displayed (01~06 above)
01 CURR STATUS Current status of the LAN printer (READ ONLY FIELD)
When “DESTINATION” is PC, this field will display “OFF” until PC is
connected.
02 EMPTY BUFF Prints all data left in the buffer
03 UPDATE LAN Applies modified items
When making any TCP/LAN related parameter, select “YES” to update
LAN (and save) for changes to take effect.
04 DESTINATION Select the device where your report prints.
05 PRINTER IP Sets the IP address of the LAN printer
06 PRINTER TCP Enter TCP port of printer (see printer manufacturer specifications)
07 LAN TCP Displays LAN TCP port of the associated service shown in table above
(READ ONLY)
08 RETRY COUNT Retransfer attempt count (00~10)
09 RETRY WAIT Wait time for retransfer(005~250 sec)
10 PJL ENABLE Sets PJL (0. FALSE, 1. TRUE)
11 LANGUAGE Printer language(0. RAW, 1. PCL, 2. PS)
12 PAPER SIZE Paper size (0. A4, 1. LETTER)
13 FONT TYPE Font type (0. COURIED, 1. TIMES NEW ROMAN)
