Samsung OFFICESERV 7100 - MMC: 218 RELAY TYPE

OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 JANUARY 2009
MMC: 218 RELAY TYPE
DESCRIPTION:
This MMC defines the uses of the 2 relays on the MP10/MP10a card. These relays may
be defined as EXTERNAL PAGE, COMMON BELL, LOUD BELL or NOT USED.
DIAL OPTION DESCRIPTION
0 EXTERNAL PAGE This relay type will operate when assigned to an
external page zone in MMC 605.
1 COMMON BELL This relay type can be assigned as a member of a
station group in MMC 601.
2 LOUD BELL This relay type can be associated or paired to a
station (MMC 205) with an audible tone output to an
external Amplifier.
3 NOT USED Relays programmed as NOT USED have no defined
function.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
RELEASE Used to store data and advance to next MMC
HOLD Clears previous entry
ACTION DISPLAY
1. Press TRSF 218
Display shows first relay
[362] RELAY TYPE
EXTERNAL PAGE
2. Dial relay number
OR
[363] RELAY TYPE
EXTERNAL PAGE
Use UP or DOWN to scroll through relay
numbers and use soft keys to move cursor
3. Dial relay type, e.g., 2
OR
[363] RELAY TYPE
COMMON BELL
Use UP or DOWN to scroll through relay
types and use soft keys to move cursor
