OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 204 COMMON BELL CONTROL
DESCRIPTION:
Determines whether the common bell relay contact has an interrupted or
continuous closure when activated. If interrupted is chosen, the relay follows an
internal C.O. ring pattern of one second closed followed by three seconds open. By
default the common bell relay pair is assigned.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 204
Display shows current setting
[204] COM. BELL
CONTINUOUS
2. Dial common bell number
[363] COM. BELL
CONTINUOUS
3. Dial 0 for continuous or 1 for interrupted
operation
[363] COM. BELL
INTERRUPTED
OR
Use UP or DOWN to scroll through options
Press RIGHT soft key to return to step 2.
4. Press TRANSFER to store and exit
OR
Press SPEAKER to store and advance to
next MMC.
DEFAULT DATA: CONTINUOUS
RELATED ITEMS: MMC 203 ASSIGN UA DEVICE
MMC 218 RELAY TYPE
MMC 601 ASSIGN STATION GROUP
MMC 724 MISC NUM PLAN
