MMC: 838 PRIVATE IP ADDRESS
DESCRIPTION:
This optional MMC provides a means for the MP10/MP10a to communicate with
remote VoIP gateways on a network consisting of a mixture of private and public IP
addresses. If your network consists of IP addressing that is entirely private OR
entirely public, you do not need to utilize this MMC. There are 80 entries.
¾ NOTE: When changing any IP address/value, listed below, three digits must
be input for each (octet) field. Example 192.168.1.10 input must be: 192 168
001 010
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 838.
Display shows the first available option.
PRIVATE IP (01)
0. 0. 0. 0
Press UP or DOWN key to select an entry
OR
Press the RIGHT soft key to move cursor.
2. Press UP or DOWN key to select an option
OR
PRIVATE IP (01)
0. 0. 0. 0
Press RIGHT soft key to move cursor.
3. Enter IP address in 3 digit entry format. IE
105.52.10.20 is input 105.052.010.020.
PRIVATE IP (01)
105. 052. 010.020
Press RIGHT soft key to enter data and
move cursor to the Step 1 position.
4. Press UP or DOWN key to select another
entry OR Press RIGHT soft key to move
PRIVATE IP (01)
105. 052. 010.020
cursor
OR
Press TRANSFER to store and exit OR press
SPEAKER to store and advance to next MMC.
PRIVATE IP (01)
105. 052. 010.020
