OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 511 MSG WAITING LAMP CADENCE
DESCRIPTION:
This MMC defines the cadence (flash rate) of single line telephone message waiting
lamps on phones connected to a 16MWSLI. There are two main choices for the MW
lamp cadence available, these being continuous and interrupted as described
below. This 4SLM card supports message waiting however SLT phones connected
to the 4SLM card(s) are not affected by this setting. Only 16MWSLI ports are
affected on the OS 7100.
OPTION KEYS
0 INTERRUPTED The MW lamp will flash at a rate determined by the timer
settings. The shortest on time is 100ms and the longest on
time is 3000ms. The shortest off time is 100ms and the
longest off time is 3000ms. The timer is adjusted in 100ms
increments.
1 CONTINUOUS When a 16MWSLI port has a message, the lamp will be lit
steady.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SPEAKER Used to store data and advance to next MMC
ANS/RLS Used to select ALL
ACTION DISPLAY
1. Press TRANSFER 511.
Display shows.
MW LAMP CADENCE
CONTINUOUS LED
2. Press 0 or 1 to select CADENCE
OR
MW LAMP CADENCE
INTERRUPT LED
Press UP or DOWN key to make selection
Press RIGHT soft key to advance to step 3.
3. Dial new values for interrupt times
(four digits).
MW LAMP CADENCE
2000 2000
