OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 826 CLOCK SOURCE
DESCRIPTION:
This MMC determines which span the system will take its clocking from. Priority 1 is
the first choice. Assign this to the cabinet and slot you want to clock to first. Then if
this span is down decide which other span will be the second priority and so on.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
ACTION DISPLAY
1. Press TRANSFER 826.
Display shows.
REFERENCE CLOCK
PRIORITY 1: C1-S1
2. Press UP or DOWN key to select
priority (1-9)
REFERENCE CLOCK
PRIORITY 3: C1-S1
OR
3. Press RIGHT soft key to move cursor
then press UP and DOWN key to
REFERENCE CLOCK
PRIORITY 3: C2-S3
select cabinet and slot.
4. Press TRANSFER to store and EXIT or
Press SPEAKER to store and advance to next
MMC.
DEFAULT DATA: PRIORITY 1: C1-S1
RELATED ITEMS: CLK LED ON DTPRI CARDS
