OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 JANUARY 2009
MMC: 763
3. NEXT ROUTE: This option determines where the translated OUT DIGIT string
should be sent. Valid entries are as follows:
LCR
The OUT DIGIT string will be sent to the system LCR for
further routing. This is the default setting.
TRUNK Number This trunk will be accessed to send the OUT DIGIT string.
TRUNK GROUP
Number
A trunk out of this group will be accessed to send the
OUT DIGIT string.
In addition to the 198 table entries there are two special entries, 199 and 200. Entry
199 is used to route failed calls and entry 200 is used to route calls with no
matching entry. These entries are programmed as follows:
199. FAIL ROUTE: This option determines where the IN DIGIT string will be sent
if the translation routine fails. This can occur if the specified
trunk route is busy or out of order. By default this value is
set to LCR. Valid entries are the same as the NEXT ROUTE
option above.
200. NO MATCH RT: This option determines where the received digit string will be
sent if there are no matching IN DIGIT entries in the table.
By default this value is set to LCR. Valid entries are the same
as the NEXT ROUTE option above.
PROGRAM KEYS
VOLUME UP & DOWN Used to scroll through options
KEYPAD Used to input selections
RIGHT & LEFT SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
HOLD Used to clear current entry
ACTION DISPLAY
1. Press TRANSFER 763.
Display shows.
(001)IN DIGIT
2. Dial table entry number (e.g. 105)
OR
(001)IN DIGIT
To Next Page
