OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 MAY 2009
MMC: 831
3. Press RIGHT soft key to move cursor to IP
address line.
[3801] IP ADDRESS
168.219. 76.101
4. Using the keypad enter three digit IP octet
numbers IE 192 168 001 050 for 192.168.1.50
[3801] IP ADDRESS
105.052.010.050
5. Cursor will return to Step 2 upon completion
of IP address entry.
[3801] IP ADDRESS
105. 52. 10. 50
6. Press UP or DOWN key to make selection.
Press RIGHT soft key to move cursor.
[3801] GATEWAY
168.219. 76. 1
7. Press RIGHT softkey to move cursor to
gateway address line.
[3801] GATEWAY
168.219. 76. 1
8. Using the keypad enter three digit IP octet
numbers IE 192 168 001 001 for 192.168.1.1
[3801] GATEWAY
192.168.001.001
9. Cursor will return to Step 2 upon completion
of gateway entry.
[3801] GATEWAY
192.168. 1. 1
10. Press UP or DOWN key to make selection
Press RIGHT soft key to move cursor
[3801] SUB MASK
255.255.255 0
11. Using the keypad enter three digit gateway
address numbers.
[3801] SUB MASK
255.255.255 0
12. Cursor will return to Step 2 upon completion
of sub mask entry.
[3801] SUB MASK
255.255.255 0
13. Press UP or DOWN key to make a selection
OR
[3801] PUBLIC IP
1. 1. 1. 1
14. Press TRANSFER to store and exit
OR
Press SPEAKER to store and advance to next
MMC.
DEFAULT DATA: IP ADDRESS: 0.0.0.0
GATEWAY: 0.0.0.0
SUB MASK: 255.255.255
IP TYPE: PRIVATE ONLY
LOCAL RTP: 30000
CARD RESET: NO
