OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 MAY 2009
MMC: 835
TOS/DiffSrv: An eight-bit binary value that will be utilized by external
routers, switches, etc (that optionally support TOS-bit/DiffServ
prioritization) – to identify the transport-priority value of data
packets generated by the MGI card. This value can be left at
default value (00000000) if your network infrastructure does
not support this method of bandwidth management
802.1 p/q: Enables/disables VLAN tagging on the MGI resources
802.1 P: Assigns a priority to the VLAN tag
802.1 VLAN: Assigns a VLAN ID to the MGI
G711 FRAME: Determines the frame length for the G.711 codec. Default is
20 milliseconds. Range is 10 ms ~ 60 msec.
G729 FRAME: Determines the frame length for the G.729 codec. Default is
20 milliseconds. Valid values are 20, 40, and 60 msec.
G729a FRAME: Determines the frame length for the G.729a codec. Default is
20 milliseconds. Valid values are 20, 40, and 60 msec.
G723 FRAME: Determines the frame length for the G.729 codec. Default is
30 milliseconds. Valid values are 30 and 60 msec.
NOTE: The settings in this MMC to do not affect ITP to ITP calls where both
keysets are on the same subnet. For these types of calls an MGI
channel is not used, so settings in MMC 840 and MMC 841 take effect.
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 835.
Display shows the first option.
MGI6:AUDIO CODEC
G.729A
2. Press RIGHT soft key to move cursor.
OR
MGI6:AUDIO CODEC
G.729A
Press UP or DOWN key to select a parameter.
3. Press RIGHT soft key to move cursor.
MGI6:AUDIO CODEC
G.729A
