OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 MAY 2009
MMC: 837
• GEN NO RESP: Before sending Cancel for General Request, the User Agent
shall wait for this amount of time. The range is 0~99900.
• REQ RETRY: After sending General Request, the User Agent shall wait for
the Final Response for this amount of time. The range is
0~99900.
EXT: SIP Extension Configuration
• IP-UMS PORT: UDP Socket port number to communicate with the
OfficeServ IP-UMS.
• EXPIRE TIME: Expiration time period for SIP stations registration. When
OfficeServ gives a valid response for SIP stations REGISTER
request, OfficeServ informs the SIP station that the
registration will be valid for the time period specified in this
field. Unit is a second.
• SIGNAL PORT: UDP Socket port number which is open for SIP station.
TRK: SIP Trunk Configuration
• iBG EXPIRE: Expiration time period for Ubigate’s registration. Ubigate
acts as a SIP station.
• INCOM MODE: This option selects how incoming calls are routed: FOLLOW
DID TRANS (MMC 714), FOLLOW TRUNK RING (MMC 406),
FOLLOW INCOM DGT (MMC 406)
• PEER CLIPTB: This option determines the CLI table in MMC 321 to use for
SIP Peering
• RCV CLI FWD: This option, when enabled, passes incoming CLI when
transferring SIP calls to other destinations
• DEFAULT ISP: For future use. If OfficeServ can interoperate with multiple
ITSPs at the same time, this field used to select the default
one.
ISP1-4: SIP Carrier Options
• SIP Server: This option enables or disables the SIP profile.
