OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 MAY 2009
MMC: 857
VIRTUAL ASSIGNMENT TYPES:
SLT: Virtual extension (Single Line Telephone)
DGT: Virtual extension (Digital Telephone )
WIRED ITP: Wired IP Phone extensions
WLAN ITP: Wireless IP handset extensions
SIP STN: SIP Station extensions
GCONF STN: Group Conference station resources
SPNET TRK: SPNet trunks for IP networking between OfficeServ systems
SIP TRK: SIP Trunk numbers
H323 TRK: H.323 Trunk numbers
MOBEX STN: MOBEX station extensions
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
HOLD Used to clear previous entry
ACTION DISPLAY
1. Press TRANSFER 857.
Display shows.
C4-S01:SLT
SLT
2. Enter number 4-5 for cabinet number
And enter 1-12 for slot number.
C4-S01:SLT
SLT
OR
Press volume button to scroll
3. Press volume button to scroll card type and
Select card type by pressing RIGHT soft key.
C4-S01:SLT
DGP
4. Press TRANSFER button to save and exit
OR
Press SPEAKER button to advance to the next
MMC.
