7.33
Date Code 20080213 Instruction Manual SEL-351A Relay
Inputs, Outputs, Timers, and Other Control Logic
Output Contacts
q PULSE command is also available via the front panel ({CNTRL} pushbutton, output contact testing option).
Execution of the PULSE command results in a logical 1 input into the above logic (one-second default pulse width).
w Output contacts OUT101–ALARM are configurable as a- or b-type output contacts. See Table 2 .2 for more information on
selecting output contact type.
e Main board jumper JMP23 allows output contact OUT107 to operate as: regular output contact OUT107 (JMP23 in
position 2-3), an extra Alarm output contact (JMP23 in position 1-2). See Table 2 .3 and Tab le 2 .4 for more information on
jumper JMP23.
Figure 7.26 Logic Flow for Example Output Contact Operation
OpenOUT101 (a)De-energizedLogical 0OUT101
OUT101
PULSE OUT101
Output
Contact
Coil States
SEL
OGIC
Control
Equations
Settings
Relay
Word
Bits
Example
Relay
Word Bits
States
Serial Port
Commands
(see q)
Output Contacts
(and example
contact types)
(see w)
Output
Contact
Terminal
States
ClosedOUT102 (a)EnergizedLogical 1OUT102
OUT102
PULSE OUT102
OpenOUT103 (a)De-energizedLogical 0OUT103
OUT103
PULSE OUT103
OpenOUT104 (a)De-energizedLogical 0OUT104
OUT104
PULSE OUT104
ClosedOUT105 (b)De-energizedLogical 0OUT105
OUT105
PULSE OUT105
OpenOUT106 (b)EnergizedLogical 1OUT106
OUT106
PULSE OUT106
OpenOUT107 (b)Energized
Energized
or
De-energized
Logical 1 (relay OK)
or
Logical 0 (relay failed)
Logical 1
(Position 2—3)
(Position 1—2)
JMP23
(see e)
Alarm
Logic/
Circuitry
OUT107
OUT107
PULSE OUT107
PULSE ALARM
Relay Enters Access Level 2
Open (relay OK)
or
Closed (relay failed,
de-energized,
etc.)
ALARM (b)
ALARM
Closed (relay OK)
or
Open (relay failed,
de-energized,
etc.)
ALARM (a)
