SEL-351A Settings Sheets
Relay Settings (Serial Port Command SET and Front Panel)
SEL-351A Relay Instruction Manual Date Code 20080213
Date________________
SV10 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps) SV10DO =
SV11 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV11PU =
SV11 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV11DO =
SV12 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV12PU =
SV12 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV12DO =
SV13 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV13PU =
SV13 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV13DO =
SV14 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV14PU =
SV14 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV14DO =
SV15 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV15PU =
SV15 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV15DO =
SV16 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV16PU =
SV16 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV16DO =
