SET.16
of 32
SEL-351A Settings Sheets
SEL
OGIC Control Equation Settings (Serial Port Command SET L)
SEL-351A Relay Instruction Manual Date Code 20080213
Date________________
Reset Latch Bit LT2 RST2 =
Set Latch Bit LT3
SET3 =
Reset Latch Bit LT3
RST3 =
Set Latch Bit LT4
SET4 =
Reset Latch Bit LT4
RST4 =
Set Latch Bit LT5
SET5 =
Reset Latch Bit LT5
RST5 =
Set Latch Bit LT6
SET6 =
Reset latch Bit LT6
RST6 =
Set Latch Bit LT7
SET7 =
Reset Latch Bit LT7
RST7 =
Set Latch Bit LT8
SET8 =
Reset Latch Bit LT8
RST8 =
Set Latch Bit LT9
SET9 =
Reset Latch Bit LT9
RST9 =
Set Latch Bit LT10
SET10 =
Reset Latch Bit LT10
RST10 =
Set Latch Bit LT11
SET11 =
Reset Latch Bit LT11
RST11 =
Set Latch Bit LT12
SET12 =
Reset Latch Bit LT12
RST12 =
Set Latch Bit LT13
SET13 =
Reset Latch Bit LT13
RST13 =
Set Latch Bit LT14
SET14 =
Reset latch Bit LT14
RST14 =
Set Latch Bit LT15
SET15 =
Reset Latch Bit LT15
RST15 =
Set Latch Bit LT16
SET16 =
Reset Latch Bit LT16
RST16 =
Torque Control Equations for Inst./Def.-Time Overcurrent Elements
[NOTE: torque control equation settings cannot be set directly to logical 0.]
Level 1 phase (see Figure 3.3)
67P1TC =
