SEL-351A Settings Sheets
SEL
OGIC Control Equation Settings (Serial Port Command SET L)
Display Point DP11 DP11 =
Display Point DP12
DP12 =
Display Point DP13
DP13 =
Display Point DP14
DP14 =
Display Point DP15
DP15 =
Display Point DP16
DP16 =
Setting Group Selection Equations (See Table 7.4)
Select Setting Group 1 SS1 =
Select Setting Group 2
SS2 =
Select Setting Group 3
SS3 =
Select Setting Group 4
SS4 =
Select Setting Group 5
SS5 =
Select Setting Group 6
SS6 =
Other Equations
Event report trigger conditions (see Section 12) ER =
Fault indication [used in INST, A, B, and C target logic and
other relay functions, see subsection SEL
OGIC Control
Equation Setting FAULT on page 5.13]
FAULT =
Block synchronism check elements (see Figure 3.27)
BSYNCH =
Close bus monitor (see Figure 5.3)
CLMON =
Breaker monitor initiation (see Figure 8.3)
BKMON =
Enable for zero-sequence voltage-polarized, sensitive neutral,
and channel IN current-polarized directional elements (see
Figure 4.7)
E32IV =
