Appendix K
ACSELERATOR QuickSet SEL-5030 Software
Overview
The ACSELERATOR
®
QuickSet
™
SEL-5030 software is an easy-to-use yet
powerful tool to help get the most out of your SEL-351A relay.
Using
ACSELERATOR QuickSet, you will be able to:
➤ Create, test, and manage settings with a Windows
®
interface.
➤ Visually design SELOGIC
®
control equations with a powerful
Logic Editor.
➤ Verify SELOGIC control equations with an integrated Logic
Simulator.
➤ Analyze power system events from SEL relays with integrated
Waveform and Harmonic Analysis tools.
➤ Communicate with SEL devices via an HMI interface with
integrated Meter and Control functions.
➤ Create, manage, copy, merge, and read relay settings with a
settings database manager.
This document gives instructions for installing
ACSELERATOR QuickSet
software. A Quick Tour guide is available as part of the online help. After
installation, the Quick Tour will show how to create a circuit breaker (CB)
simulator. The CB simulator is useful for testing and evaluation.
NOTE: Like all SEL relay products,
the SEL-351A can also be set and
operated by a simple ASCII terminal.
NOTE: Using ACSELERATOR QuickSet
in SEL-351A relays requires relay
Firmware Version R104 or later.
