Siemens SINUMERIK 828D Commissioning Manual

5.26 Variable S_NCCODEREADONLY
Description
The screen property S_NCCODEREADONLY is only relevant when a cycle is recompiled in
the editor with a "Run MyScreens" dialog. S_NCCODEREADONLY determines whether a
recompiled NC code from the editor can be changed or not.
The following applies for the return value:
●
TRUE: The recompiled NC code from the editor can be changed
● FALSE: The recompiled NC code from the editor cannot be changed (read-only), because,
for example, it is already in the preprocessing (= TRUE).
5.27 Variables S_RESX and S_RESY
Description
The current resolution or its X and Y component can be queried in the configuration with the
screen properties S_RESX and S_RESY.
Example
REG[0] = S_RESY
See also
RESOLUTION (Page 105)
Variables
5.27 Variables S_RESX and S_RESY
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 89

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
