MD28450 $MC_MM_TOOL_DATA_CHG_BUFF_SIZE Buffer for changing tool data (DRAM).
= 100 Number of entries in the buffer for the OPI change service for tool data. Dynamic memory
is used. This buffer
is only created if either bit 2 or bit 3 is set in MD17530 $MN_TOOL_DA‐
TA_CHANGE_COUNTER.
MD19320 $ON_TECHNO_FUNCTION_MASK
= 10H
Bit 4 Enables the tool monitoring function with magazine management.
9.1.2 Configuring the access levels of the tool management
Access levels for selected parameters
MD51199 $MNS_ACCESS_WRITE_TM_GRIND Access level, write TM grinding data.
MD51200 $MNS_ACCESS_WRITE_TM_GEO Access level, write TM geometry data.
MD51201 $MNS_ACCESS_WRITE_TM_WEAR Access level, write TM wear data.
MD51202 $MNS_ACCESS_WRITE_TM_WEAR_DELTA Access level, restricted writing of tool
wear values.
MD51203 $MNS_ACCESS_WRITE_TM_SC Access level, write TM additive offsets.
MD51204 $MNS_ACCESS_WRITE_TM_EC Access level, write TM operating off‐
sets.
MD51205 $MNS_ACCESS_WRITE_TM_SUPVIS Access level, write TM monitoring data.
MD51206 $MNS_ACCESS_WRITE_TM_ASSDNO Access level, write TM unique D num‐
ber.
MD51207 $MNS_ACCESS_WRITE_TM_WGROUP Access level, write TM wear groups
(magazine location / magazine).
MD51208 $MNS_ACCESS_WRITE_TM_ADAPT Access level, write TM tool adapter ge‐
ometry data.
MD51209 $MNS_ACCESS_WRITE_TM_NAME Access level, write TM tool name and
duplo.
MD51210 $MNS_ACCESS_WRITE_TM_TYPE Access level, write TM tool type.
The access level of individual parameters can be overlaid through settings in the
<PARAMETERCONFIGURATION> tag, "Access level" entry (see SectionConfiguring list
parameters (Page 249)).
Tool management
9.1 Machine data for tool management
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 223
