4.4 Machine data for Advanced Surface
Machine data for Advanced Surface
The following setpoints are recommended for the listed machine data in order to achieve the
optimum workpiece surface when machining mold workpieces:
General machine data:
MD number Designation Default set‐
ting
Recom‐
mendation
Data
class
Parameter
10200 $MN_INT_INCR_PER_MM 100000 100000 M --
10210 $MN_INT_INCR_PER_DEG 100000 100000 M --
10682 $MN_CONTOUR_SAMPLING_FACTOR 1 1 M --
Channel-specific machine data:
MD number Designation Default set‐
ting
Recom‐
mendation
Data
class
Parameter
20150[3] $MC_GCODE_RESET_VALUES 3 3 M FIFOCTRL
20150[44] $MC_GCODE_RESET_VALUES 2 2 M UPATH
20170 $MC_COMPRESS_BLOCK_PATH_LIMIT 20 20 M --
20172 $MC_COMPRESS_VELO_TOL 60000 1000 M --
20443[0] $MC_LOOKAH_FFORM 0 0 M DYNNORM
20443[1] $MC_LOOKAH_FFORM 0 0 M DYNPOS
20443[2] $MC_LOOKAH_FFORM 0 1 M DYNROUGH
20443[3] $MC_LOOKAH_FFORM 0 1 M DYNSEMIFIN
20443[4] $MC_LOOKAH_FFORM 0 1 M DYNFINISH
20455 $MC_LOOKAH_FUNCTION_MASK 0 0 M --
20480 $MC_SMOOTHING_MODE 0 0 M --
20482 $MC_COMPRESSOR_MODE 100 100 M --
20485 $MC_COMPRESS_SMOOTH_FACTOR[0-4] 0 0 M --
20486 $MC_COMPRESS_SPLINE_DEGREE[0-4] 3 3 M --
20490 $MC_IGNORE_OVL_FACTOR_FOR_ADIS 1 1 M --
20550 $MC_EXACT_POS_MODE 3 3 M --
20600[0] $MC_MAX_PATH_JERK 10000 10000 M DYNNORM
20600[1] $MC_MAX_PATH_JERK 10000 10000 M DYNPOS
20600[2] $MC_MAX_PATH_JERK 10000 10000 M DYNROUGH
20600[3] $MC_MAX_PATH_JERK 10000 10000 M DYNSEMIFIN
20600[4] $MC_MAX_PATH_JERK 10000 10000 M DYNFINISH
20602[0] $MC_CURV_EFFECT_ON_PATH_ACCEL 0 0 M --
20602[1] $MC_CURV_EFFECT_ON_PATH_ACCEL 0 0 M --
20602[2] $MC_CURV_EFFECT_ON_PATH_ACCEL 0,6 0,65 M --
20602[3] $MC_CURV_EFFECT_ON_PATH_ACCEL 0,6 0,6 M --
20602[4] $MC_CURV_EFFECT_ON_PATH_ACCEL 0,6 0,5 M --
Parameterizing machine data
4.4 Machine data for Advanced Surface
CNC commissioning
82 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
