Identifier <tag> for the following setting:
<DETAILSCONFIGURATION>
Configuring the "Details" window (Page 266)
<MAGAZINEPLACENAMECONFIGURATION>
Assigning a name for magazines and magazine
locations
(Page 269)
<MULTITOOLPLACETOOLTIPCONFIGURATION>
Configuring the "Assign
Tooltips for Multitool Lo‐
cations" window
(Page 271)
<PLACETYPECONFIGURATION>
Assigning a name for magazine location types
(Page
271)
<COORDSYSMAGAZINEASSIGNMENT>
Assignment between magazines
and magazine
locations and coordinate systems
(Page 274)
<FILTERCONFIGURATION>
Disabling the softkey depending on filters
(Page
276)
<LOADSTATIONSHANDLEALLTOOLS>
Configuring the "Load Station Selection" win‐
dow
(Page 277)
<CHANNELMAGAZINEASSIGNMENT>
Assignment of magazines and magazine loca‐
tions to channels
(Page 273
)
<TOOLCHANGEREASON>
Reason for the tool change when reactivating
(Page
281)
<IDENTCONNECTIONCONFIGURATION>
Configure the code carrier connection
(Page
284)
<SAVETOOLDATACONFIGURATION>
Configuring Save to file (Page 287)
9.2.1 General settings
<SETTINGS> tag
The general settings for the tool management user interface are stored in the <SETTINGS>
tag.
Entries Meaning
ReactivateWithMagPos True - reactivate with positioning of the tool to the tool mag‐
azine loading point.
False
-
default
setting,
reactivate without positioning the tool
magazine.
ReactivateAllMonitorModes True - the actual values of all the monitoring types set in the
NC are reset.
False - default setting,
actual value of the active monitoring
type is reset.
ReactivateEnabled True - default setting, reactivation is enabled.
False - reactivation is disabled.
CreateNewToolDialog True - the "New Tool" window is displayed. In this window,
you
can specify the
tool name and the size of the tool (over‐
sized tool) before actually creating the tool. Other input op‐
tions can be defined by configuring the "New tool" window.
False - default setting, the "New Tool" window is not dis‐
played. Once the name has been entered, the tool will be
created directly in the tool list.
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
230 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
