4.6.2 To save and load data
Save data to a file
Procedure:
1. Select the "Save data to a file" option.
2. In the data structure, select the data that you want to save to a file and confirm with "OK".
3. Select as the storage location, a directory or a USB storage medium and enter a name.
Note
SINAMICS parameters
An ASCII file (*.TEA) is always generated when saving.
Three files of the following type are generated when saving the drive data:
●
A binary file (*.ACX) that cannot be read.
● An ASCII file (*.TEA) that can be read or edited in the ASCII editor.
● A log file (*.log) that contains message texts (error situation) or is empty (successful
storage).
Loading data from a file
NOTICE
Protection of the machine
For safety reasons, the
machine and setting data should only be transferred when the enable
is locked.
Procedure:
1.
Select the "Load data from a file" option.
2.
In the data structure, select the saved file and confirm with "OK".
3.
In the drop-down list, select an object, e.g. a different axis or a different drive object, to
which you want to transfer the data and confirm with "OK".
4.
Observe the safety instructions and check the enable signals at the machine and the drive.
5. For drive data, the "Load" softkey is used to transfer the data to the target object.
Parameterizing machine data
4.6 Managing data
CNC commissioning
90 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
