Definition of the buffer storage with allocation to the magazines:
$TC_MAP1[9998]=7
$TC_MAP2[9998]="Buffer1"
$TC_MAP3[9998]=17
$TC_MAP6[9998]=1
$TC_MAP7[9998]=2
$TC_MAP8[9998]=0
$TC_MPP1[9998,1]=2
$TC_MPP2[9998,1]=0
$TC_MPP3[9998,1]=0
$TC_MPP4[9998,1]=2
$TC_MPP5[9998,2]=1
$TC_MPP1[9998,2]=2
$TC_MPP2[9998,2]=0
$TC_MPP3[9998,2]=0
$TC_MPP4[9998,2]=2
$TC_MPP5[9998,2]=2
$TC_MAP1[9999]=9
$TC_MAP2[9999]="LOADINGMAGAZINE1"
$TC_MAP3[9999]=17
$TC_MAP7[9999]=1
$TC_MAP8[9999]=0
$TC_MPP1[9999,1]=7
$TC_MPP2[9999,1]=0
$TC_MPP3[9999,1]=0
$TC_MPP4[9999,1]=2
$TC_MDP1[1,1]=0
$TC_MDP1[2,1]=0
$TC_MDP2[1,1]=0
$TC_MDP2[2,2]=0
9.2.15 Assigning a name for magazines and magazine locations
<MAGAZINEPLACENAMECONFIGURATION> tag
The entries to assign dedicated magazine location names are located in the
<MAGAZINEPLACENAMECONFIGURATION> tag. Magazine locations
can be displayed with
texts. Instead of the identifier, e.g. 1/5 for the first magazine, location five, the configured text
is then output in the tool lists.
Entries Meaning
MAGAZINE_XXX XXX stands for the magazine number.
PLACE_XXX XXX stands for the location number.
Name Text identifier of the magazine location.
Example
<MAGAZINEPLACENAMECONFIGURATION>
<MAGAZINE_9998>
<Name value="TM_SPECIAL_MAG_PLACE_1" type="QString" />
</PLACE_2>
</MAGAZINE_9998>
<MAGAZINE_1>
<Name value="TM_SPECIAL_MAG_PLACE_2" type="QString" />
</PLACE_3>
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 269
