7.7 Swiveling
7.7.1
Technology cycles for swiveling
Requirement
Only applies for technology milling.
The commissioning of the kinematic chain of the machine is a mandatory requirement for
correct swiveling functionality (CYCLE800). The kinematic chain is stored in the tool
parameters $TC_CARR1 to $TC_CARR65.
Note
The vectors of the kinematic chain can be determined with the "Measure kinematics"
measuring function (CYCLE996).
A tool carrier is available in the 828D for activating the swivel function.
MD18088 $MN_MM_NUM_TOOL_CARRIER Maximum number of definable toolholders
Default, cannot be changed
MD28082 $MC_MM_SYSTEM_FRAME_MASK System frames (SRAM)
Default, cannot be changed
Activating the swivel function
The swivel function is enabled on the user interface via the following channel-machine data:
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function screen
Bit 0 = 1 Enable swivel
Configuring the input dialog
You can configure the input screen for swiveling using the following channel-specific cycle
setting data. The setting data is effective for all of the declared swivel data sets.
SD55221 $SCS_FUNKTION_MASK_SWIVEL_SET Function screen, swiveling CYCLE800
Bit 0 Input field "No swiveling"
= 0 Hide
= 1 Display
Bit 1 Selection text in retraction "Z", "ZXY" or "Fixed point 1/2"
= 0 Display text Z = "Z", display text ZXY = "ZXY"
Configuring cycles
7.7 Swiveling
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 135
