Element values
You can change the buffer location type with the parameters in the "Location" window:
Parameters Description
(Selection menu) Select a buffer type
● Tool spindle / tool holder
● Loader
● Gripper
●
Transfer location
Index The index counts the locations of a type.
9.8.4.3 Define loading location
Loading location are loading points or loading stations. All loading locations are stored in an
internal loading magazine with the number 9999. The number of loading locations is defined
from the "Magazine" window.
The loading location type is defined from the "Location" window.
Directory values
You are currently located under the "Active data" → <tool unit> → <loading magazine> directory
in the "Commissioning" → "NC" →"Tool management" operating area.
You can define the following parameters in the "Magazine" window from the loading magazine
directory:
Parameters Description
Name Designation of the loading magazine
The designation is displayed in the tree structure.
Magazine number 9999 (cannot be changed)
Locations Number of loading locations
Tool management
9.8 Editor for the tool and magazine management
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 317
