Mode M Line value Z Column value S Output value
4 Search concept:
Search in column S
Column index of search col‐
umn
Line index
5 Line index of search line. Search concept:
Search in line Z
Column index
Compare mode
When
compare mode C = 0 is used, the content of the search line or search column must be
sorted in ascending order. If the search concept is smaller than the first element or greater
than the last, the value 0 or a blank string is output and the error variable ERR is set to TRUE.
When compare mode C = 1 is used, the search concept must be present in the search line or
search column. If the search concept cannot be found, the value 0 or a blank string is output
and the error variable ERR is set to TRUE.
7.2.2 Example Access to an array element
Prerequisite
Two arrays are defined below. These are the basis for the following examples:
//A(Thread)
(0.3 / 0.075 / 0.202)
(0.4 / 0.1 / 0.270)
(0.5 / 0.125 / 0.338)
(0.6 / 0.15 / 0.406)
(0.8 / 0.2 / 0.540)
(1.0 / 0.25 / 0.676)
(1.2 / 0.25 / 0.676)
(1.4 / 0.3 / 1.010)
(1.7 / 0.35 / 1.246)
//END
//A(Array2)
("DES" / "PTCH" / "CDM" )
(0.3 / 0.075 / 0.202 )
(0.4 / 0.1 / 0.270 )
(0.5 / 0.125 / 0.338 )
(0.6 / 0.15 / 0.406 )
(0.8 / 0.2 / 0.540 )
(1.0 / 0.25 / 0.676 )
(1.2 / 0.25 / 0.676 )
Graphic and logic elements
7.2 Defining an array
SINUMERIK Integrate Run MyScreens
168 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3
