Syntax: Identifier [S,[M[,C]]].val] or
Identifier [S,[M[,C]]] or
Description: Access to one-dimensional array with only one line
Syntax: Identifier [Z,S,[M[,C]]].val or
Identifier [Z,S,[M[,C]]]
Description: Access to two-dimensional array
Parameters: Identifier: Name of array
Z: Line value (line index or search concept)
S: Column value (column index or search concept)
M: Access mode
0 Direct
1 Searches the line, column directly
2 Searches the column, line directly
3 Searches
4 Searches line index
5 Searches column index
C: Compare mode
0 Search concept must be located in the range of values
of the line or column.
1 Search concept must be located exactly.
Example:
VAR1 = MET_G[REG[3],1,0].VAL ;Assign Var1 a value from
array MET_G
Access mode
● "Direct" access mode
With "Direct" access mode (M = 0), the array is accessed with the line index in Z and the
column index in S. Compare mode C is not evaluated.
● "Search" access mode
In
the case of access mode M = 1, 2 or 3, the search always commences in line 0 or column
0.
Mode M Line value Z Column value S Output value
0 Line index Column index Value from line Z and column
S
1 Search concept:
Search in column 0
Column index of column
from which value is read
Value from line found and
column S
2 Line index of line from
which return value is read
Search concept:
Search in line 0
Value from line Z and column
found
3 Search concept:
Search in column 0
Search concept:
Search in line 0
Value from line and column
found
Graphic and logic elements
7.2 Defining an array
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 167
