- OR -
Press the "Cancel" softkey to cancel the changes.
Changing operands
Depending on the type of operand, you can increment or decrement the address by 1 place
at a time using the "Operand +" and "Operand -" softkeys.
Note
Axis names as index
For axis names, the "Operand +" and "Operand -" softkeys do not act as index, e.g. for
$AA_IM[X1].
Examples
DB97.DBX2.5
Result: DB97.DBX2.6
$AA_IM[1]
Result: $AA_IM[2]
MB201
Result: MB200
/Channel/Parameter/R[u1,3]
Result: /Channel/Parameter/R[u1,2]
10.1.2 Saving and loading screen forms
You have the option of saving the configurations of the variables made in the "NC/PLC
variables" window in a screen form that you reload again when required.
Editing screen forms
If you change a screen form that has been loaded, then this is marked using with * after the
screen form name.
The name of a screen form is kept in the display after switching-off.
Procedure
1. You have entered values for the desired variables in the "NC/PLC varia‐
bles" window.
2. Press the ">>" softkey.
Service and diagnostics
10.1 NC/PLC variables
SINUMERIK Operate
324 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
