6.5 Optimize the spindle
6.5.1
Set the machine data for the spindle
Checking the machine data settings
Match the machine data default settings as well as all relevant parameters for spindle/axis
interpolation with the machine data in the following table. The example is true for a spindle
motor without mechanical gearbox stages with 8000 rpm.
The
machine
data
can be initialized with the suggested values shown in the table. The values
vary depending on the application.
Number Designation Value Meaning
MD30300 $MA_IS_ROT_AX 1 Rotary axis / spindle
MD30310 $MA_ROT_IS_MODULO 1 Modulo conversion for rotary axis / spindle
MD30320 $MA_DISPLAY_IS_MODULO 1 360-degree modulo display for rotary axis
or spindle
MD32000 $MA_MAX_AX_VELO 8000 Maximum axis velocity
MD32010 $MA_JOG_VELO_RAPID 60 Rapid traverse in jog mode
MD32020 $MA_JOG_VELO 10 Jog axis velocity
MD32040 $MA_JOG_REV_VELO_RAPID 60 Revolutional feedrate in JOG mode with
rapid traverse override
MD32050 $MA_JOG_REV_VELO 10 Revolutional feedrate for jog
MD32200[0] $MA_POSCTRL_GAIN x K
V
factor: as tuned
MD32200[1] $MA_POSCTRL_GAIN x
MD32620 $MA_FFW_MODE 3 Feedforward control type
MD32640 $MA_STIFFNESS_CONTROL_ENABLE 1 Dynamic stiffness control
MD32810[0] $MA_EQUIV_SPEEDCTRL_TIME x Equivalent time constant speed control
loop for feedforward control: as tuned
MD32810[1] $MA_EQUIV_SPEEDCTRL_TIME x
MD33000 $MA_FIPO_TYPE 3 Fine interpolator type
MD34000 $MA_REFP_CAM_IS_ACTIVE 0 Axis with reference point cams
MD34020 $MA_REFP_VELO_SEARCH_CAM 30 Reference point approach velocity
MD34020 $MA_REFP_VELO_SEARCH_CAM 30
MD34040[0] $MA_REFP_VELO_SEARCH_MARKER 30 Creep velocity
MD34040[1] $MA_REFP_VELO_SEARCH_MARKER 30
MD34060[0] $MA_REFP_MAX_MARKER_DIST 370 Maximal distance to the reference mark
MD34060[1] $MA_REFP_MAX_MARKER_DIST 370
MD35000 $MA_SPIND_ASSIGN_TO_MACHAX 1 Assignment of spindle to the machine axis
MD35100 $MA_SPIND_VELO_LIMIT 8000 Maximum spindle speed
MD35110[0] $MA_GEAR_STEP_MAX_VELO 8000 Maximum speed for gear stage change
MD35110[1] $MA_GEAR_STEP_MAX_VELO 8000
MD35130[0] $MA_GEAR_STEP_MAX_VELO_LIMIT 8000 Maximum speed of gear stage
MD35130[1] $MA_GEAR_STEP_MAX_VELO_LIMIT 8000
Tuning
6.5 Optimize the spindle
CNC commissioning
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 195
