9.2.4 List of tool types
Coding of tool types for milling tools
Group with type 1xy (milling tool):
100 Milling tool according to CLDATA (DIN 66215)
110 Ballhead cutter (cylindrical die milling tool)
111 Ballhead cutter (tapered die milling tool)
120 End mill (without corner rounding)
121 End mill (with corner rounding)
130 Angle head cutter (without corner rounding)
131 Angle head cutter (with corner rounding)
140 Facing cutter
145 Thread cutter
150 Side mill
151 Saw
155 Bevel cutter (without corner rounding)
156 Bevel cutter (with corner rounding)
157 Tapered die-sinking cutter
160 Drill and thread milling cutter
Coding of tool types for drills
Group type 2xy (drills):
200 Twist drill
205 Solid drill
210 Boring bar
220 Center drill
230 Countersink
231 Counterbore
240 Tap regular thread
241 Tap fine thread
242 Tap Whitworth thread
250 Reamer
Coding of tool types for grinding tools
Group type 4xy (grinding tools):
400 Grinding wheel circumference
410 Face grinding wheel
490 Dresser
494 Dressing roller for cylindrical grinding
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 253
