The screen position can be defined as follows:
●
The screen position can be specified in "Pixels in relation to 640x480".
Example:
//M(MyMask/"MyCaption"/"\\myhelp.png"/0,219,335,174)
● The screen position can be coupled to the resolution-dependent position of a form panel
from an Operate standard screen layout, e.g. "Form panel4" ("auxiliary functions") from the
screen layout "slmastandardscreenlayout.SlMaStandardScreenLayout" of the "Machine"
area
//M(MyMask/"MyCaption"/"\
\myhelp.png"/"slmastandardscreenlayout.SlMaStandardScreenLayout.FormPanel4")
It is therefore easy to superimpose standard forms from Operate or position Easyscreen
screens precisely at their position.
Example:
//M(Mask/"Mask"//"slstandardscreenlayout.SlStandardScreenLayout.LowerForm")
Any other screen layout can also be used.
● The screen position can be coupled to a self-defined, resolution-dependent definition of
form panels in the easyscreen.ini file.
Example:
//M(MyMask/"MyCaption"/"\\myhelp.png"/"MyPanel")
3.6 Notes for personnel changing over to "Run MyScreens"
Note
When using HMI Operate in the NCU, note that all file names are saved in lower case letters
on the CF card (com, png, txt).
Note
Make sure that the coding is set to UTF-8 in the editor that you are using when saving the
configuration and language files.
Image files
Image files must be saved in the PNG format (xxx.png).
The data must be saved, e.g. for OEM modifications, under
[System oem directory]
/ico/[Resolution]
For further information, see also Chapter Using display images/graphics (Page 50).
Fundamentals
3.6 Notes for personnel changing over to "Run MyScreens"
SINUMERIK Integrate Run MyScreens
34 Programming Manual, 10/2015, 6FC5397-3DP40-5BA3
