DefaultLineSpacing=3
Notes:
● The "SymmetricalAspectRatio" entry determines whether the same aspect ratio is used in
the X and Y direction when adapting a configuration to a specific screen resolution.
– "false" (default): Fields and graphics are shortened in widescreen resolution in the Y
direction (asymmetrical elongation in relation to 640x480). For example, a square
configured in 640x480 is shortened vertically for a widescreen panel and becomes a
rectangle.
– "true": The same aspect ratio is used in the X and Y direction and fields and graphics
retain their originally configured proportions in relation to 640x480. For example, a
square configured in 640x480 remains a square in a widescreen panel.
● The entries "DefaultLineHeight" and "DefaultLineSpacing" can be used to specify the
default line height (default: 18 pixels) and the default line spacing (default: 3 pixels) in
relation to 640x480. They only take effect when no Y position or height is specified in the
configuration for the position of the short text or the input/output field.
Resolution-dependent screen position: Form panels
Entry in easyscreen.ini:
[640x480]
MyPanel = x:=0, y:=220, width:=340, height:=174
[800x480]
MyPanel = x:=0, y:=220, width:=420, height:=174
...
Notes:
