Parameters Description
Tool search Search strategy:
● Without search strategy
● Take from the TOA
● Active tool
●
Shortest way
Empty location search Search strategy:
● Without search strategy
● Take from the TOA
● First location forwards
●
Current location forwards
● Current location backwards
● Last location backwards
● Symmetric current location
● 1:1 exchange
Location coding
● Variable
● Fixed-location coded
Location type Identification for the magazine location type
(Changes the value globally for all locations in the magazine)
Consider adjacent location
● Yes
●
No
(Changes the value globally for all locations in the magazine)
Note
If one of the Location type or Consider adjacent location parameters is changed individually
and the value is not identical for all locations, the "Variable" definition appears in the display.
Element values
You can change the magazine location type with the parameters in the "Location" window:
Parameters Description
Location type Identification for the magazine location type
Consider adjacent location
● Yes
● No
9.8.4.5 Link assignments
You can establish the mechanical relationship between the individual components of the tool
unit in the "Assignment" window.
Tool management
9.8 Editor for the tool and magazine management
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 319
