- OR -
If the session file with this name already exists, then you obtain a corre‐
sponding confirmation prompt.
10.4.5.3 Load trace session file
You have the option of loading already saved session data, to restart them or to display the
trace that has been recorded.
Settings Meaning
Variables, settings You can restart a trace session that has already been created.
Variables, settings and recorded val‐
ues
You can view the result of a trace session, change the variable
and if required, restart.
Precondition
A session file of recorded traces is available.
Procedure
1. You have selected the "Trace" function.
2. Press the "Load trace" softkey.
The "Load Session File: Please Select File" window opens.
3. Select the desired session file from the appropriate directory, e.g. "Trace",
and press the "Display trace" softkey.
The "Load trace: session..." is opened.
4. Select the checkbox "Variables, settings", if you wish to immediately start
the trace session.
5. Press the "OK" softkey and the "Start trace" softkey to restart the
trace.
- OR -
Select the checkbox "Variables, settings and recorded values", if you wish
to display the trace session.
Press the "OK" softkey.
The data of the selected session are loaded displayed in the "Trace"
window.
Service and diagnostics
10.4 Trace
SINUMERIK Operate
362 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
