Identifier Parameter or property System variable
*)
PlateAngle Cutting tip angle, combination of cutting parameter 24
and cutting parameter 10
$TC_DP24 and
$TC_DP10
NoseAngle Nose angle, cutting parameter 24 $TC_DP24
CuttRate Cutting rate, cutting parameter 25 $TC_DP25
SpindleDirection For rotating tools, direction of rotation of the tool spin‐
dle. For turning tools, direction of rotation of the main
spindle
$TC_DP25 bit8 and
bit9
Coolant1 Coolant 1 $TC_DP25 Bit10
Coolant2 Coolant 2 $TC_DP25 Bit11
MFunction1 M function 1 $TC_DP25 Bit0
MFunction2 M function 2 $TC_DP25 Bit1
MFunction3 M function 3 $TC_DP25 Bit2
MFunction4 M function 4 $TC_DP25 Bit3
IsoHNoDPH ISO H number $TC_DPH
OrientNo Cutting orientation $TC_DPV
OrientV1 Cutting orientation vector 1 $TC_DPV3
OrientV2 Cutting orientation vector 2 $TC_DPV4
OrientV3 Cutting orientation vector 3 $TC_DPV5
OrientVGeoAx1 Cutting orientation vector of geometry axis 1, cutting
orientation parameter 3, e.g. vector X
$TC_DPVN3
OrientVGeoAx3 Cutting orientation vector of geometry axis 3, cutting
orientation parameter 4, e.g. vector Z
$TC_DPVN4
OrientVGeoAx2 Cutting orientation vector of geometry axis 2, cutting
orientation parameter 5, e.g. vector Y
$TC_DPVN5
TeethCount Number of teeth, cutting parameter 34 $TC_DPNT
UniqueDNo Unique D number $TC_DPCE
EdgeUser_1, ..., Edge‐
User_10,
OEM cutting parameters 1 to 10 $TC_DPC1, ...
$TC_DPC10
EdgeAppl_1, ..., Edge‐
Appl_10x
Siemens application cutting parameters 1 to 10 $TC_DPCS1, ...
$TC_DPCS10
*)
Parameter corresponds to the
system variable or the system variable is the basis for this parameter.
9.2.2.3 Monitoring parameter identifiers
For the monitoring parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
SupWarning Warning limits, taking the current monitoring type
into consideration
-
SupRemaining Actual value, taking the current monitoring type into
consideration
-
SupDesired Setpoint, taking the current monitoring type into
consideration
-
SupWarningTime Tool life warning limit $TC_MOP1
SupRemainingTime Tool life actual value $TC_MOP2
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
244 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
