The programming in the NC program is called:
T4 MTL=1
Example
The following table shows
the task status and the preparation of the acknowledgment with the
position specification for the change.
Data block Meaning Value
DB4300.DBB0 Task 10000001
DB4300.DBB1 Task description 00010110
DB4300.DBW6 Source magazine number 1
DB4300.DBW8 Source location number 4
DB4300.DBW10 Target magazine number 9998
DB4300.DBW12 Target location number 1
DB4300.DBW56 Multitool type 1
DB4300.DBW58 Multitool location count 2
DB4300.DBD60 Multitool distance 1.0000
DB4300.DBW64 Source multitool number 2
DB4300.DBW66 Source multitool location number 1
DB4300.DBW68 Target multitool number 0
DB4300.DBW70 Target multitool location number 0
DB4200.DBB0 Acknowledgment 00000001
DB4200.DBW4 Multitool location number 0
In a replacement cycle for T, $C_MTL_PROG can read whether MTL was programmed. The
programmed value for MTL can be read with $C_MTL .
The acknowledgment is made with the total acknowledgment.
DB4200.DBW4: For the acknowledgment, the actual position of the multitool on the NC can
be notified in this data item. If the position does not match the position requested in the NC
task, an alarm is triggered. If the position is not notified to the NC (DB4200.DBW4 = 0), no
check of the correct multitool position is made. Value "0" is permitted only for the total
acknowledgment.
9.8 Editor for the tool and magazine management
9.8.1 Overview
The tool management offers the possibility to define all real tool magazines and internal
magazines with
the appropriate properties from the operating software and link them channel-
specific with the tool unit. You can configure the relationships between tool magazine, griper
and spindle via a tree view.
Tool management
9.8 Editor for the tool and magazine management
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 311
