9.2.2.6 Magazine location adapter parameter identifiers
The following identifiers are used in the configuration file for the magazine location adapter
parameters:
Identifier Parameter or property System variable
*)
MagPlaceAdapterLength1 Magazine location adapter length 1 $TC_ADPT1
MagPlaceAdapterLengthGeoAx1 Magazine location adapter geometry axis 1 $TC_ADPT1
MagPlaceAdapterLength2 Magazine location adapter length 2 $TC_ADPT2
MagPlaceAdapterLengthGeoAx3 Magazine location adapter geometry axis 3 $TC_ADPT2
MagPlaceAdapterLength3 Magazine location adapter length 3 $TC_ADPT3
MagPlaceAdapterLengthGeoAx2 Magazine location adapter geometry axis 2 $TC_ADPT3
MagPlaceAdapterTrafoNo Magazine location adapter transformation
number
$TC_ADPT4
*)
Parameter corresponds to the system variable or the system variable is the basis for this parameter.
9.2.2.7 Multitool parameter identifiers
For the multitool parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
MultiToolNo Number of the multitool -
MultiToolNumberOfPlaces Number of multitool locations $TC_MTPN
MultiToolNumberOfPlacesRO Number of multitool locations, only read ac‐
cess
$TC_MTPN
MultiToolIdent Name of the multitool $TC_MTP2
MultiToolInMag Magazine in which the multitool is located $A_TOOLMN
MultiToolInPlace Magazine location containing the multitool $A_TOOLMLN
MultiToolInMagInPlace Magazine number/Magazine location $A_TOOLMN /
$A_TOOLMLN
MultiToolMyMag Owner magazine of the multitool $A_MYMN
MultiToolMyPlace Owner magazine location of the multitool $A_MYMLN
MultiToolPlaceSpec Location type $TC_MTP7
MultiToolPlaceSpecIdent Location type as text $TC_MTP7
MultiToolSizeLeft Multitool size to the left in half locations $TC_MTP3
MultiToolSizeRight Multitool size to the right in half locations $TC_MTP4
MultiToolSizeUpper Multitool size to the top in half locations $TC_MTP5
MultiToolSizeDown Multitool size to the bottom in half locations $TC_MTP6
MultiToolOverSize Multitool size as fixed setting - two half lo‐
cations
left, two half
locations right, one half
location top, one half location bottom
$TC_MTP3 -
$TC_MTP6
MultiToolPosition Multitool position $TC_MTP_POS
MultiToolProtAreaFile File name of the multitool description which
is
required to determine
the protection zone
$TC_MTP_PROTA
MultiToolKindOfDist Type of distance input of the multitool loca‐
tions
$TC_MTP_KD
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 247
