Customizing the "Machine" operating area
5
Automatic changeover
The
circumstances under which
an automatic changeover is made into the "Machine" operating
area are set in MD51040 $MNS_SWITCH_TO_MACHINE_MASK.
MD51040 $MNS_SWITCH_TO_MACHINE_MASK 0 (default setting)
Bit 0 = 1 For program selection in the Program Manager, an automatic change is not made into
the Machine operating area.
Bit 1 = 1 For program selection in the Program Manager, an automatic change is not made into
the Machine operating area.
When changing over the operating mode via the machine control panel, an automatic
change is not made into the Machine operating area.
Bit 2 = 1 For program selection in the Program operating area, an automatic change is not made
into the Machine operating area.
Bit 3 = 1 When selecting a program/executing a program in the Program operating area, the block
search is not automatically started.
5.1 Setting the font size of the actual value display
Setting font size
The actual values for
the machine coordinate system or workpiece coordinate system can be
displayed in two different font sizes in the "Machine" operating area.
Using a channel machine data item, you can set how many axes should be displayed in a
larger font.
MD52010 $MCS_DISP_NUM_AXIS_BIG_FONT Number of actual values with a large
font
= 3 Number of actual values with a larger font (default setting)
5.2 Inserting a user-specific logo
OEM-specific logo
The Siemens logo is visible in the header of the "Machine" operating area.
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 49
