495 Dressing roller for surface grinding
496 Dressing wheel for cylindrical grinding
497 Dressing wheel for surface grinding
Grinding tool types 401, 402, 403 as well as 411, 412, 413 are not listed as tool types that can
be selected. The grinding-specific tool monitoring - taking into account the basic dimension
when calculating the grinding wheel radius - is set using dedicated parameters. These
parameters act on the tool types in the usual form.
Coding of tool types for turning tools
Group type 5xy (turning tools):
500 Roughing tool
510 Finishing tool
520 Plunge cutter
530 Parting tool
540 Threading tool
550 Steel profile
560 Rotary drill (ECOCUT)
580 Orientated probe
585 Calibration tool
Coding of tool types for special tools
Group type 7xy (special tools):
700 Slotting saw
710 3D probe
711 Edge probe
712 Mono probe
713 L probe
714 Star probe
725 Calibration tool
730 Stop
731 Spindle sleeves
732 End support
900 Auxiliary tools
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
254 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
