● Both channels are assigned TO unit 1.
Channel 1:
MD28085 $MC_MM_LINK_TOA_UNIT Assigns TO unit to a channel (SRAM)
= 1 The channel is assigned TO unit 1.
Channel 2:
MD28085 $MC_MM_LINK_TOA_UNIT Assigns TO unit to a channel (SRAM)
= 2 The channel is assigned TO unit 1.
● Each channel is assigned a toolholder.
Channel 1:
MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER Toolholder number
= 1 The channel is assigned toolholder 1.
Channel 2:
MD20124 $MC_TOOL_MANAGEMENT_TOOLHOLDER Toolholder number
= 2 The channel is assigned toolholder 2.
7RROKROGHU
%XIIHUPDJD]LQH
0DJD]LQHORFDWLRQ
7&B0'3>@ 
0DJD]LQH
ORFDWLRQVWR
72$&KDQQHODQGFKDQQHO
0DJD]LQH
ORFDWLRQVWR
7RROKROGHU
%XIIHUPDJD]LQH
0DJD]LQHORFDWLRQ
7&B0'3>@ 
/RDGLQJPDJD]LQH
0DJD]LQHORFDWLRQ
7&B0'3>@ 
7&B0'3>@ 
Figure 9-1 Magazine configuration
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
268 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
