Entries Meaning
CreateNewMultiToolDialog True - default setting, the "New Multitool" window is dis‐
played. In this window, you can configure the following be‐
fore actually creating the multitool:
● Multitool names
● Number of multitool locations
● Type of clearance input
●
Value of the location clearance for each multitool location
False - the "New Multitool" window is not displayed. Once
the name has been entered, the multitool will be created
directly in the tool list.
MagazineSelectionDialog True - a dialog box displaying the buffer, tool magazine and
NC memory is displayed. A mark can be added to or re‐
moved from each of
these elements to indicate whether that
element appears in the list display. The "Go to" softkey can
be used to select an element directly in the list display.
False - no dialog box for magazine selection. The system
switches between the buffer, the tool magazines and the
NC memory.
If there is no MagazineSelectionDialog entry in the
<Settings> tag, the dialog box is automatically displayed
with more than one tool magazine (excluding the system
magazine) when magazine configuration is taking place. If
there is only one tool magazine, the switchover function is
used.
NewToolFavoritesOnly Refers to the "New tool" function.
True - only those
tool types that are configured as favorites
are listed.
False - default setting, all tool types are listed.
SortationInFirstEtcLevel True - the "Sorting" function is placed at the first softkey
level. The "Continue" function is omitted.
False - default setting, sorting at all softkey levels.
ToolBufferOnceOnTop True - default setting, buffer is displayed at the start of the
list.
False - buffer is displayed for each magazine. Only those
locations are displayed that are assigned to the magazine.
UnloadToolFromLoadPlaceEnabled True - a tool at the load station can be removed from the
load station using the "Unload" softkey.
False
- default setting.
The "Unload" softkey is not displayed
for a tool at the load position.
CreateNewToolWithCuttPos9Enabled True - cutting edge position 9 is offered in the cutting edge
position selection.
True - default setting, cutting edge position 9 is not offered
in the cutting edge position selection.
AutoHNumberDisplayEnabled Column of the cutting edge parameter "IsoHNoDPH - ISO
H number" depending on the machine configuration.
True
- default setting,
the column is automatically displayed.
False - the column is not automatically displayed.
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 231
