Entries Meaning
AutoUniqueDNumberDisplayEnabled Column of the cutting edge parameter "UniqueDNo" de‐
pending on the machine configuration.
True - default setting,
the column is automatically displayed.
False - the column is not automatically displayed.
AccessLevelDeleteAllDNos The following entry specifies the access level as of which
the "Delete all D numbers delete" function is offered.
Default setting: Access level 3 (user) - relevant only when
the "Unique D number" setting has been made.
MagazineNumberOfDCheckAndActivate Default setting: -2 - the tools of all magazines are considered
by the function "Check for unique D number and activate
tool."
>0 - The above function only considers the tools of the
named magazine.
AutoFixedPlaceDisplayEnabled Column of the tool parameter "ToolStateFixed" - tool status
- tool is fixed-location coded and acts dependent on the
magazine configuration.
True
- default setting,
the column is automatically hidden, if
all of the configured magazines are fixed location coded.
False - the column is not automatically hidden.
MagPlaceAdapterDisplayEnabled Columns of the magazine location adapter parameters are
displayed in the "Magazine" window.
False - default setting, parameters are not displayed.
AdaptTransDataViewEnabled The magazine location adapter transformed display of the
cutting edge parameters is enabled. It can be switched on
and off in the settings dialog of the tool lists.
False
- default setting,
the magazine location adapter trans‐
formed display of the cutting edge parameters is not ena‐
bled.
ActiveCompensationsEnabled The "Working offsets" function is enabled. This function de‐
pends on the machine configuration. Unique D number,
magazine location adapter and magazine management
must be set.
False - default setting, the "Working offsets" function is not
enabled.
M2NLockEnabled Locking of an M to N switchover while a function of the tool
management is being executed.
True - default setting, switchover is locked.
SDToolLengthInListEnabled True - default setting, evaluation of SD42940, SD42942,
and SD42950 in axis name display in the tool lists.
False - the setting data are not evaluated in the axis name
display.
DisableMultiTools True - even though the Multitools function is set in the NC,
they are not offered in the tool lists.
False
- default setting,
if the Multitools function is set in the
NC, they are offered in the tool lists.
Tool management
9.2 Configuring the user interface
