Entries Meaning
CursorPositionInfoEnabled True - information about the tool on which the cursor is posi‐
tioned is written to the SlCap local variable "/Hmi/TMHMI‐
CurData".
False - default setting, no information about the tool on
which the cursor is positioned is made available on an in‐
terface for the OA.
EnableMonAndBasisGrindingToolTypes True - enable switchover of grinding tool types in respect of
"with/without grinding-specific tool monitoring," "with/with‐
out consideration of the base dimension when calculating
the grinding wheel radius."
False - default setting, switchover not enabled.
ErrorMessageWithoutProgressBar True - error messages are output without a progress bar
and must be acknowledged via softkey.
False - default setting, error message is automatically
closed when the progress bar reaches the end.
ColumnZoomByResolution True - column width is adapted to the resolution of the HMI.
False - default setting, the column width is adapted to the
font
size in the
HMI. With this setting, with higher resolutions
more columns can be displayed next to each other without
needing to scroll.
AccessLevelReadDetailsAllParameter The following entry specifies the access level as of which
the "Further details" function
is offered in the "Details" dialog.
Default setting: Access level 7 (keyswitch position 0) - can
be overlaid through the setting in MD51198.
FixNumberOfMultiToolPlaces Multitools are created with a fixed number of multitool loca‐
tions. There is no prompt when you create the multitool.
FixKindOfDistInMultiTools Multitools are created with a fixed type of clearance input of
the
multitool locations. There
is no prompt when you create
the multitool.
Possible input value: 3 - clearance of the multitool locations
as an angle.
DlDisplayMode
● DisplayDistributed - default setting,
the setup offsets EC
are displayed in the tool list and the additive offsets SC
are displayed in the tool wear list.
● EcInWearList - the setup offsets EC are displayed in the
tool wear list and the additive offsets SC are not
displayed.
