MD28450 $MC_MM_TOOL_DATA_CHG_BUFF_SIZE Buffer for changing tool data (DRAM).
= 100 Number of entries in the buffer for the OPI change service for tool data. Dynamic memory
is used. This buffer
is only created if either bit 2 or bit 3 is set in MD17530 $MN_TOOL_DA‐
TA_CHANGE_COUNTER.
MD19320 $ON_TECHNO_FUNCTION_MASK
=2000000H
Bit 25 = 0 Tool monitoring function not enabled without magazine management.
Setting with magazine management
Make the following settings
if you are commissioning the tool management with NC magazine
management:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK Memory for the tool management is re‐
served step by step (SRAM).
= 13FH
Bit 0 = 1 Provide tool management data.
Bit 1 = 1 Provide monitoring data.
Bit 6 = 0 Magazines not divided into wear groups.
Note
Machine data MD18080 can only be set for the technology variants cylindrical and surface
grinding.
MD20310 $MC_TOOL_MANAGEMENT_MASK Activating the tool management functions.
= 420FH
Bit 0 = 1 Magazine management active.
Bit 1 = 1 Monitoring functions of tool management active.
MD17530 $MN_TOOL_DATA_CHANGE_COUNTER Marking the changed tool data for HMI.
= 1FH
Bit 0 Tool status change.
Bit 1 Tool remaining unit quantity change.
Bit 2 Tool data change service.
Bit 3 Magazine data in the change service.
Bit 4 ISO data in the change service.
Tool management
9.1 Machine data for tool management
SINUMERIK Operate
222 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
