Icon (optional) icon for display in the machining step program, format
Screen size for corresponding resolution:
640 X 480 mm → 16 x 16 pixels
800 X 600 mm → 20 x 20 pixels
1024 X 768 mm → 26 x 26 pixels
1280 X 1024 mm → 26 x 26 pixels
1280 X 768 mm → 26 x 26 pixels
Archive:
[system user directory]
/ico/ico<resolution>
Note: For resolutions of 1280, the folder for 1024 x 768 mm is used
(only suitable for machining step programs).
Desc_Text (optional) Explanation text for display in the machining step pro‐
gram, max. length of string is 17 characters (only suitable for ma‐
chining step programs).
Example
//M(TestGC/"Code generation:")
DEF VAR1 = (R//1)
DEF VAR2 = (R//2)
DEF D_NAME
LOAD
VAR1 = 123
VAR2 = -6
END_LOAD
OUTPUT(CODE1)
"Cycle123(" VAR1 "," VAR2 ")"
"M30"
END_OUTPUT
PRESS(VS1)
D_NAME = "\MPF.DIR\MESSEN.MPF"
GC("CODE1",D_NAME) ;Write NC code from the OUTPUT method to
file \MPF.DIR\MESSEN.MPF:
Cycle123(123, -6)
M30
END_PRESS
Programming commands
6.3 Functions
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 149
