By6=6
By7=7
END_LOAD
PRESS(HS1)
Byte.wr=2
END_PRESS
CHANGE(Byte)
By1=byte+1
By2=byte+2
By3=byte+3
By6=byte+6
By7=byte+7
Feed.VAR="EB"<<By3
Spin.VAR="EB"<<Byte
Custom1.VAR="EB"<<By6
Custom2.VAR="EB"<<By7
Axisstop.VAR="E"<<By2<<".2"
Spinstop.VAR="E"<<By2<<".4"
Byte.wr=1
END_CHANGE
CHANGE(Axis stop)
IF Axistop==0
Axistop.BC=9
ELSE
Axistop.BC=11
ENDIF
END_CHANGE
CHANGE(Spin stop)
IF Spinstop==0
Spinstop.BC=9
ELSE
Spinstop.BC=11
ENDIF
END_CHANGE
//END
"Custom" operating area
8.4 Programming example for the "Custom" area
SINUMERIK Integrate Run MyScreens
Programming Manual, 10/2015, 6FC5397-3DP40-5BA3 191
